Battery Charger
Battery Charger
We are engaged in offering high quality Battery Charger that works efficiently with both genset and main supply. It is based on high frequency switching technology, supports a wide input voltage range, and delivers almost ripple-free DC output.
With features like high efficiency, compact design, and lightweight construction, this charger ensures faster charging, longer service life, and reliable performance. It is suitable for both cyclic and standby applications.
Key Features
- ✔ Works with genset & main supply
- ✔ Wide input voltage range
- ✔ High efficiency & fast charging
- ✔ Compact, lightweight & durable
- ✔ Ripple-free DC output
- ✔ Suitable for cyclic & standby use
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 12V & 24V / 50A |
| Input Supply | 1 Phase, 2 Wire, 50 Hz AC |
| Voltage Range | 185 - 270 VAC |
| Frequency Tolerance | ±5% |
| Rectifier Type | |
| Float Mode | 13.5VDC / 27.0VDC |
| Boost Mode | 14.1VDC / 28.2VDC |
| Voltage Regulation | ±1% |
| Output Current | 50 Amps DC |
| Ripple | 2% RMS |
| Cooling | Force Air Cooled |
Protection & Controls
Protections:
- ✔ Short Circuit Protection (Auto Recovery)
- ✔ Over Voltage Protection
- ✔ Input Under/Over Voltage Protection
- ✔ Overload Protection
Indicators & Controls:
- ✔ Charger ON / Fail Indication
- ✔ Over Temperature Indication
- ✔ Float & Boost Indicators
- ✔ DC Ammeter & Voltmeter
- ✔ Input AC Voltmeter & Ammeter
- ✔ Float / Boost Selector
- ✔ Auto / Manual Selector
- ✔ Input & Battery MCB
Why Choose Our Battery Charger?
Our battery chargers are designed for high efficiency, fast charging, and long operational life. With advanced protection systems and stable output performance, they ensure safe and reliable battery charging for industrial and commercial applications.
